cookies packaging machine | Boshi Pack Full Automatic Feeder Cookies Biscuit Packing Line Machine
The advantage of three servo motor horizontal flow packing machine
1)Three servo motor version, high speed output, stable operation, saving time and film.
2)Interface features easy and quick setting and operation.
3)Self failure diagnosis, clear failure display.
4)High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5)Temperature independent PID control, more suitable for packaging different materials.
6)Positioned stop function, without sticking knife or wasting film.
7)Simple driving system, reliable working, convenient maintenance.
8)All control is realized through software, easy for function adjusting and technical upgraded.
cookies packaging machine | Boshi Pack Full Automatic Feeder Cookies Biscuit Packing Line Machine
Product advantages:
* Self-fault diagnosis is available for clear fault display.
* The interface is easy and quick to set up and operate with high-precision structures.
* The three servo motor version of the pillow packaging machine has high-speed output to ensure stable operation, saving time and film.
* With PLC touch screen and fully automatic measuring, filling, bagging, date printing/nitrogen charge/string bags/easy tearing packing in one step, easy and accurate to set the bag length.
3 big advantages of Boshi packing
(such as laminated film, ((PET/ PE, OPP/CPP,OPP/ CE)), paper.
cookies packaging mach
(Standard export wooden cases.)
| Model | BS-250 |
| Film width | Max.250mm |
| Film thickness | 0.03-0.1mm |
| Bag width | 30-110 mm |
| Bag length | 65-190 mm, or 120-280mm |
| Product height | 55 mm |
| Packing speed | 40-230 bags/ min |
| Power | 2.4 KW |
| Machine dimensions | 3770*680*1420 mm |
| Machine weight | about 500 kg |
| Option devices | Date printer, hole puncher, label machine |
| Packing film materials | OPP, CPP, OPP/PE, PET/ PE, Aluminum, and etc. |
